The Monsoon Mini Wet Downdraft Table offers a durable and affordable solution for effective and safe source capture of combustible dust. With no permanent ducting or central installation required, its compact, self-contained, patent-pending design achieves a high-face velocity, featuring up to 300 FPM, with minimal footprint within your facility.
The Monsoon Mini pulls airborne particles and contaminants through its ventilated work surface and moves them into a water torrent. Once bonded with water droplets, the dust particles drain down to the bottom of the collector for safe removal. Interior baffling creates the required turbulence to maximize filtration efficiency while preventing water vapor from leaving the exhaust, avoiding excess humidity.
The Monsoon Mini Wet Downdraft Table comes fitted with four (4) heavy duty castors for easy portability. The cabinet’s stainless steel construction guards against corrosion and the collector’s internal components can be removed for easy cleaning.
Designed for the safe collection of combustible metal dusts, ideal applications include: aluminum, magnesium, titanium, grinding & deburring, sanding & finishing, 3D printing, chemical dust and buffing. Compliant with NFPA guidelines for combustible dust
Features
- Flexible 30” x 36” Worksurface
- High Capture Face Velocity (300 FPM)
- 3 HP TEFC Motor producing 1200 CFM of Airflow
- Stainless Steel Anti-corrosion Construction
- Low Water auto-shutdown
- Blue Rubber Grid Matting
- Manual Water Refill
